Valco - MK1PUP1 Terminal Microswitch, plastic 1CO

Valco - MK1PUP1

Terminal Microswitch, plastic 1CO

MK1PUP1 is a Micro Switch Terminal, plastic 1CO, with a metal short lever on a wheel

Features

• Contact: 1CO
• Actuator: Slim piston
• Current: 6A (250V AC)
• Usage category: AC15
• Current: 10A
• Usage class: AC12
• Mechanical life (Min. Qty.): 10000000
• Electrical life (minimum quantity): 100000
• Operating frequency: (On-Off/Hour) Mech. 3000 El. 1200
• Insulation voltage: (Ui)660V
• Impulse withstand voltage: (Uimp) 2.5 kV
• Dielectric Strength: (Body-Contact) 1.890V AC
• Dielectric Strength: (Contact-Contact)1.890V AC
• Isolation resistance 10 MΩ min. (500V DC)
• Operating temperature -25 / +80 °C
• Degree of Protection: IP20
• Contact material: AgNi
• Cable terminal section: 6.3*0.8mm
• Short circuit breaking capacity: (Ics)1 kA
• Material: Plastic

The set contents

1x Valco - MK1PUP1 Terminal Microswitch, plastic 1CO
