RP-Onesto - RCBO KRCS2pro Miniature circuit breaker 1P+N C20A 6kA Type A 30mA With Overload Protection

Click Image for Gallery

RP-Onesto - RCBO Miniature circuit breaker

1P+N C20A 6kA Type A 30mA With Overload Protection

The Onesto KRCS2pro RCBO (Residual Current Circuit Breaker with Overload protection) is an advanced rail-mounted electrical device that combines the functions of a residual current device (RCD) and a miniature circuit breaker (MCB) in one unit. It effectively protects against electric shock (current leakage), short circuit and overload, offering safety to specific circuits.

Key Features and Benefits:

Combined Protection: Detects current leakage to earth (human protection) and excessive current flow (wiring protection).
Independent Operation: In the event of a fault, only the specific RCBO trips, keeping the rest of the house powered, unlike a general relay.
Safety: Now mandatory in new installations and renovations to protect critical circuits (sockets, kitchen, bathroom).

Product characteristics

Number of Modules : 1
Standard : IEC/EN 61009-1
Number of Poles : 1P+N
Rated Current : 20A
Rated Operatioal Voltage Ue : 230/240V
Rated Frequency Hz : 50/60Hz
Rated Impulse Withstand Voltage Uimp : 4kV
Operating Characteristic : AC/A
Instantaneous tripping current Curve: B,C
Rated residual operating current IΔn(mA):10/30
Rated short-circuit capacity (I CN )：6kA
Protection Index IP：IP20
Ambient Temperature: -25℃~﹢55℃

Package Content

1x RP-Onesto - RCBO KRCS2pro Miniature circuit breaker 1P+N C20A 6kA Type A 30mA With Overload Protection
